FPGA Security Today: Real Threats and How to Build Secure Boot and PFR

FPGA Security



FPGA-based systems power everything from industrial vision modules to embedded AI platforms and network edge devices. But recent vulnerabilities exposed in supply chains—from bootloader compromises to bitstream tampering—have elevated FPGA security from niche to mainstream concern. In 2025, developers must build secure boot processes and platform firmware resilience (PFR) into FPGA architectures by design. This article covers real-world threats, recommended mitigation strategies, and how to architect FPGA-based platforms securely.



Why FPGA security cannot be ignored

  • FPGAs often store configuration bitstreams in external flash or EEPROM. If this storage is unencrypted or unsigned, adversaries can insert malicious logic—creating persistent compromise.
  • Bootloaders that load FPGA bitstreams may lack signature verification, enabling remote firmware attacks or physical tampering.
  • Field-updatable FPGAs without proper rollback protections can be downgraded to vulnerable versions.
  • Physical access in managed products or edge nodes allows injection of side-channel attacks or hardware Trojans unless boot integrity mechanisms are enforced.
  • Recent third-party analyses revealed that attackers could intercept communication buses, modify bitstreams in transit, or inject malicious IP cores—a serious risk in defense, industrial automation, and telecom equipment.



What embedded engineers need to build

Secure boot with FPGA bitstream signature validation

Implement a root-of-trust in hardware, such as a secure MCU or FPGA logic block, that verifies a cryptographic signature before configuring the FPGA. This prevents unauthorized or tampered bitstreams from loading.

Encryption and authentication of configuration memory

Encrypted bitstream storage in external flash ensures confidentiality and integrity. Protecting the configuration bus (e.g. SPI) prevents man-in-the-middle injection during boot.

Rollback protection and version control

Prevent downgrade attacks by embedding version counters or hash-based policy. A secure bootloader should reject any bitstream with a lower version or mismatched policy.

Platform firmware resilience (PFR)

PFR techniques include hardware watchdog managers, secure fallback partitions, recovery boot modes, and power-fail protection. In FPGA systems, this must coordinate between firmware, FPGA fabric, and management controller to ensure safe recovery.

Monitoring and audit logging

Security logs—such as boot validation logs, firmware hash mismatches, and update attempts—should be recorded in protected memory and included in any compliance documentation or SBOM.



How to design secure FPGA architecture

Hardware design considerations

  • Select an FPGA family supporting encrypted bitstreams and secure boot controllers.
  • Embed a root-of-trust zone using a secure MCU or built-in FPGA security module.
  • Use tamper detection or sealed packaging for field devices, and implement boot-time integrity checks.

Firmware and update strategies

  • Sign bitstreams using ECDSA or RSA with secure key storage.
  • Encrypt configuration memory and enforce replay prevention.
  • Manage firmware versioning via immutable counters or update policy blocks.

Example resilience flow:

  • Bootloader verifies signature and integrity of the bitstream.
  • Bitstream is decrypted in encrypted boot mode or via secure logic.
  • Configuration is applied; persistent logs capture version and hash.
  • Firmware fallback partitions enable rollback in case of failure.
  • On recovery, the system resets to a known good firmware version.



Real-world industry threats and mitigations

Defense-grade IP cores and telecom systems have faced supply chain trojan attacks when insecure bitstreams allowed unauthorized logic insertion. Industrial automation devices with unsigned configurations were manipulated to bypass safety gates. To counter these threats, vendors began offering FPGA platforms with built-in secure boot mechanisms and signed image workflows.

Frameworks and SDKs now exist (for example, in Xilinx Versal or Intel Agilex devices) to support secure boot initiation, key provisioning through secure elements, and factory-provisioned root-of-trust zones.



Challenges in secure FPGA deployment

  • Legacy designs may require bitstream or bootloader redesign to support signature verification—a time-intensive effort.
  • Cryptographic modules bring area and latency penalties; designers must account for trade-offs in timing and resource consumption.
  • Managing cryptographic keys securely across production test benches and replacement parts is non-trivial.
  • Teams must maintain strict version control and rollback policies to avoid conflicts across OTA workflows.



Promotion and certification advantages

Secure boot and PFR are becoming compliance requirements under frameworks like EU Cyber Resilience Act (CRA), ISO 21434 (automotive), IEC 62443 (industrial), and many embedded safety standards. Vendors able to demonstrate bitstream integrity, signed pipelines, and audited boot logs gain a clear compliance advantage. Security-resilient FPGA designs also mitigate liability in case of cyber incidents.


Secure Boot and PFR



Challenges in secure FPGA deployment

  • Legacy designs may require bitstream or bootloader redesign to support signature verification—a time-intensive effort.
  • Cryptographic modules bring area and latency penalties; designers must account for trade-offs in timing and resource consumption.
  • Managing cryptographic keys securely across production test benches and replacement parts is non-trivial.
  • Teams must maintain strict version control and rollback policies to avoid conflicts across OTA workflows.



Promotion and certification advantages

Secure boot and PFR are becoming compliance requirements under frameworks like EU Cyber Resilience Act (CRA), ISO 21434 (automotive), IEC 62443 (industrial), and many embedded safety standards. Vendors able to demonstrate bitstream integrity, signed pipelines, and audited boot logs gain a clear compliance advantage. Security-resilient FPGA designs also mitigate liability in case of cyber incidents.



Promwad support and embedded expertise

Promwad offers embedded and security engineering services that include:

  • Secure boot integration in FPGA-based products (Xilinx, Intel, Lattice)
  • Secure bitstream generation, signing, and encryption workflows
  • PFR and fallback logic design with audit logging and version management
  • Integration with SBOM and OTA toolchains for regulated environments

We’ve supported customers in industrial vision, automotive edge platforms, and IoT systems to build secure FPGA systems that pass rigorous audit and compliance reviews.



Evaluation checklist for FPGA security

  • Check whether bitstream storage is signed and encrypted
  • Implement rollback protection policies for configuration management
  • Embed a hardware root-of-trust or secure MCU zone
  • Include audit logging in bootflow and firmware updates
  • Validate fallback and recovery mechanisms for power or update failures
  • Test bitstream injection and signature bypass against attack simulations
  • Integrate cryptographic workflows into CI/CD and deployment pipelines



Final takeaway

FPGA security is no longer optional—it is an essential aspect of embedded design in 2025. With real threats from bitstream tampering and bootloader vulnerabilities, robust strategies like secure boot and platform firmware resilience become foundational. Embedded teams and OEMs that treat FPGA design as a security-first discipline will lead in regulated markets and deliver reliable, trusted systems.
